| 브랜드 이름: | WeSeW |
| 모델 번호: | RG-717 |
| MOQ: | 1 PC |
| 가격: | Price Negotiation |
| 지불 조건: | T/T, 서부 동맹 |
| 공급 능력: | 달 당 1000000pcs |
| Specification | Model 190-2.5 | Model 170 |
|---|---|---|
| Drill Frame Height | 2500MM-2750MM (Adjustable) | 1000MM-2500MM (Adjustable) |
| Bore Depth | 2200MM-2500MM | 500MM-2500MM |
| Max Bore Diameter | 450MM | 450MM |
| Optical Axis Diameter | 25MM | 25MM |
| Optical Axis Quantity | 3 Roots | 2 or 3 Roots (Optional) |
| Gas Engine Horsepower | 15HP | 7.5HP |
| Gas Engine Displacement | 420CC | 212CC |
| Gas Engine Power | 10KW | 4KW |
| Diesel Engine Speed | 3600 RPM | 3600 RPM |
| Fuel Tank Capacity | 4.8L | 3.6L |
| Oil Capacity | 1L | 1L |
| Fuel Type | 92# Gasoline | 92# Gasoline |
| Cooling System | Air-Cooled | Air-Cooled |
| Starting Method | Manual Start (Hand Crank) | Manual Start (Hand Crank) |
| Engine Type | Single-Cylinder 4-Stroke | Single-Cylinder 4-Stroke |
| Reducer Gear Ratio | 1:10 | 1:10 |
| Reducer Weight | 35KG | 13KG |
| Transmission | Chain Drive (Reducer + Optical Axis) | Chain Drive (Reducer + Optical Axis) |
| Engine Packaging | Wooden Crate | Wooden Crate |
| Drill Packaging | Thickened Protective Film | Thickened Protective Film |
| Total Weight | 230KG | 170KG |
